Key Specs
| Engine power (gross) | SAE J1995 rated power: 27.4 kW 36.7 hp 37.2 PS at 2500 rpm |
|||
|---|---|---|---|---|
| Power take-off (PTO) power | 22.7 kW 30.4 hp |
|||
| Steering hydraulics | 15 L/min 4 gpm |
|||
| Implement hydraulics | 20.2 L/min 5.3 gpm |
|||
| Hitch type | Category 1 | |||
| Lift capacity, 24-in. behind link arms | 615 kg 1356 lb |
|||
| Standard transmission; forward/reverse | Hydrostatic transmission (HST) | |||
| Cruise control | Standard | |||
| Approximate shipping weight (open-station; cab) | Open station: 1320 kg 2910 lb Cab: Not applicable |
|||
| Wheelbase | 1723 mm 67.8 in. |
Engine
| Family | ||||
|---|---|---|---|---|
| Manufacturer | Yanmar® | |||
| Engine model | 3TNV88C-NJT | |||
| Engine power (gross) | SAE J1995 rated power: 27.4 kW 36.7 hp 37.2 PS at 2500 rpm |
|||
| Power take-off (PTO) power | 22.7 kW 30.4 hp |
|||
| Rated engine speed | 2500 rpm | |||
| Type | Direct Injection | |||
| Injection pump type | Direct Injection | |||
| Aspiration | Turbocharged | |||
| Emissions compliance | Final Tier 4 | |||
| Cylinders/displacement | Three cylinders: 1.568 L 95.8 cu in. |
|||
| Number of cylinders | Three | |||
| Cylinder liners | Cast-in-block | |||
| Bore and stroke | 86×90 mm 3.39×3.54 in. |
|||
| Compression ratio | 19.1:1 | |||
| Lubrication | Pressurized | |||
| Cooling system | Water pump | |||
| Air cleaner | Dual element | |||
| Engine torque at rated speed | 104.7 Nm 77.2 lb-ft |
|||
| Fuel tank capacity | 32 L 8.5 U.S. gal. |
